APC Smart-UPS SRT Lithium-ION 1000VA RackMount UPS 2RU
SRTL1000RMXLI – Features
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
UPS Systems using LITHIUM ION battery technology such as this are the latest offering 3x longer lifespan than standard UPS systems that use sealed lead acid battery technology with a 5 year warranty as standard these systems are the way of the future
ECO Mode
Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
LCD graphics display
Text and mimic diagrams that display modes of operation, system parameters and alarms.
Rack/Tower convertible
Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
TECHNICAL SPECIFICATIONS
Output
-
Output power capacity
900Watts / 1.0 kVA
-
Max Configurable Power (Watts)
900Watts / 1.0 kVA
-
Nominal Output Voltage
230V
-
Output Voltage Distortion
Less than 2%
-
Output Frequency (sync to mains)
50/60Hz +/- 3 Hz
-
Other Output Voltages
220, 240
-
Load Crest Factor
3 : 1
-
Topology
Double Conversion Online
-
Waveform type
Sine wave
-
Output Connections(8) IEC 320 C13 (Battery Backup)
-
Bypass
Built-in Bypass
Input
-
Nominal Input Voltage
230V
-
Input frequency
40 - 70 Hz (auto sensing)
-
Input Connections
IEC-320 C14
-
Input voltage range for main operations
50-150 (40% Load), 80 - 150V
-
Other Input Voltages
220, 240
Batteries & Runtime
-
Battery type
Li-ion
-
Typical recharge time
6hour(s)
-
Nominal Battery Voltage
48V
-
Expected Battery Life (years)
5 - 10
-
Extendable Run Time
1
-
Extended Run Options
-
Runtime
Communications & Management
-
Interface Port(s)
RJ-45 Serial , Smart-Slot , USB
-
Control panel
Multi-function LCD status and control console
-
Audible Alarm
Audible and visible alarms prioritized by severity
-
Emergency Power Off (EPO)
Yes
-
Available SmartSlot™ Interface Quantity
1
Surge Protection and Filtering
-
Surge energy rating
340Joules
Physical
-
Maximum Height
128mm , 12.8CM
-
Maximum Width
432mm , 43.2CM
-
Maximum Depth
590mm , 59.0CM
-
Rack Height
3U
-
Net Weight
25.7KG
-
Shipping weight
37.4KG
-
Shipping Height
445mm , 44.5CM
-
Shipping Width
600mm , 60.0CM
-
Shipping Depth
850mm , 85.0CM
-
Color
Black
-
Units per Pallet
6.0
Environmental
-
Operating Temperature
0 - 40 °C
-
Operating Relative Humidity
0 - 95% non-condensing %
-
Operating Elevation
0-3000meters
-
Storage Temperature
-15 - 45 °C
-
Storage Relative Humidity
0 - 95% non-condensing %
-
Storage Elevation
0-15000meters
-
Audible noise at 1 meter from surface of unit
50.0dBA
-
Online thermal dissipation
400.0BTU/hr
-
Protection Class
IP 20
Conformance
-
Approvals
CE, CE Mark, EAC, RCM, VDE
-
Standard warranty
5 year repair or replace
Sustainable Offer Status
-
RoHS
Compliant
-
REACH
REACH: Contains SVHCs
-
Battery Directive
Compliant
Additional information
| Application | Corporate & Enterprise, Servers, Security & CCTV, Audio Visual |
|---|---|
| BrandName | APC |
