Description
FEATURES
- Line-interactive UPS Topology
- Energy Saving Technology
- Active PFC Compatible
- Pure Sine Wave Output
- Automatic Voltage Regulation (AVR)
- Overload Protection
- Critical/ Non-critical Load Outlets
- Hot-swappable Batteries
- Extended Battery Module (EBM)
- Surge and Spike Protection
- EMI and RFI Filtration
- LCD Status Display
- USB Connectivity Port
- Serial Connectivity Port
- Emergency Power Off (EPO) Port
- PowerPanel? Management Software
- SNMP/ HTTP Remote Management Capability
- Rack/ Tower Convertible Configurations
TYPICAL APPLICATION
- PCs & Workstations
- Computers & Laptops
- Printers & Office Devices
- SOHO Networking Devices
- Phone/Fax/Modem
- Telecom & Network Equipment
- Video/Audio Equipment
- Industrial Equipment
- Mission-Critical Equipment
- Generator/Motor/Pump
- Back Office
- Server Room
- Data Center
FEATURE FOCUS
Critical/Noncritical Load Outlets
By dividing the outlets according to the importance of the connected loads, users are offered the flexibility to wisely manage the limited battery power during the event of power outage. In the state of a power failure, the UPS battery power can be preserve by terminating the power provided to the non-critical outlets, sparing the power to allow more runtime for critical loads to perform graceful shutdown.
Heavy-duty Rackmount Rails Included
The adjustable rackmount rails are engineered to facilitate the rack mounting of UPS or battery modules and support heavy UPS systems. Installation is quick and easy and required mounting hardware is included.
Sturdy Rackmount Ears Included
The rackmount ears are included for flexible rack mounting of UPS or battery modules. For some rack/tower convertible models, the ears also serve as supporting stands to provide stability and keep the unit upright. Installation is quick and easy and required mounting hardware is included.
GENERAL SPECIFICATIONS
Phase
| Single Phase |
UPS Topology
| Line-interactive |
Energy Saving Technology
| GreenPower UPS™ Bypass Technology |
Active PFC Compatibility
| Yes |
INPUT
Generator Compatibility
| Yes |
Nominal Input Voltage?(Vac)
| 220 |
| 230 |
| 240 |
Input Voltage Range?(Vac)
| 159 ~ 288 |
Adjustable Voltage Range?(Vac)
| 151?~?302?Vac |
Input Frequency?(Hz)
| 50 ? 3 |
| 60 ? 3 |
Input Frequency Detection
| Auto-sensing |
Rated Input Current?(A)
| 10 |
Input Connector Type
| IEC C14 | ? |
Detachable Power Cord Plug Type
| AU | ? |
Power Cord Length (ft.)
| 10 |
Power Cord Length (m.)
| 3.05 |
OUTPUT
Capacity (VA)
| 1500 |
Capacity (Watts)
| 1500 |
On Battery Waveform
| Pure Sine Wave |
On Battery Voltage(s)?(Vac)
| 220 ? 5% |
| 230 ? 5% |
| 240 ? 5% |
On Battery Frequency?(Hz)
| 50 ? 1% |
| 60 ? 1% |
Power Factor
| 1 |
Automatic Voltage Regulation (AVR)
| Double Boost, Single Buck |
Overload Protection
| Internal Current Limiting?,?Circuit Breaker |
Outlet(s) – Total
| 10 |
Outlet Type
| IEC C13?x?10 | ? |
Outlet(s) – Battery & Surge Protected
| 10 |
Outlet(s) – Critical Load (CL)
| 5 |
Outlet(s) – Non-Critical Load (NCL)
| 5 |
Typical Transfer Time?(ms)
| 4 |
BATTERY
Runtime at Half Load?(min)
| 19.1 |
Runtime at Full Load?(min)
| 6.5 |
Typical Recharge Time?(Hours)
| 3 |
Start On Battery
| Yes |
User-replaceable
| Yes |
Hot-swappable
| Yes |
Battery Type
| Sealed Lead-acid |
Replacement Battery Pack
| RBP0129 |
RBP Quantity?(pcs)
| 1 |
Extended Battery Module (EBM)
| BP48VP2U02 (Built-in Charger) |
Max. EBM Quantity?(pcs)
| Unlimited |
SURGE PROTECTION & FILTERING
Surge Suppression?(Joules)
| 2430 |
EMI/RFI Filtration
| Yes |
Network Protection RJ45
| 1-in, 1-out |
MANAGEMENT & COMMUNICATIONS
LCD Panel
| Yes |
LCD Orientation
| Rotatable LCD panel |
LCD Information Display
| Operation Type?,?Power Status?,?Battery Status?,?Load Status?,?Fault & Warning?,?Event & Log |
LCD Setting & Control
| Mode Setting?,?Alarm Setting?,?Input & Output?,?Battery Setting?,?Communication |
LED Indicators
| Power On?,?Line Mode?,?Battery Mode?,?UPS Fault |
HID Compliant USB Port(s)
| 1 |
Serial Port
| RS232 |
Dry Contact (with Relay)
| Yes |
Emergency Power Off (EPO) Port
| Yes |
Audible Alarms
| Battery Mode?,?Low Battery?,?Overload?,?Overcharge?,?Overheat?,?UPS Fault |
Management Cable?(pcs)
| Power Cord x2?,?USB Cable x1?,?Serial Cable x1?,?EPO Cable x1?,?Phone Line x1 |
Power Management Software
| PowerPanel? Business Edition |
SNMP / HTTP Remote Monitoring
| Yes – with optional RMCARD205 |
PHYSICAL
Form Factor
| Rack/Tower |
Enclosure Construction
| Metal |
Color
| Black |
Rackmount Rail
| Yes |
Rackmount Ears
| Yes |
PHYSICAL SIZE – UPS MODULE
Dimensions (WxHxD) (in.)
| 17.1 x 3.4 x 19.7 |
Dimensions (WxHxD) (mm.)
| 433 x 86.5 x 500 |
Weight (lbs.)
| 80.5 |
Weight (kg.)
| 36.5 |
Installed Rack Height?(U)
| 2 |
SHIPPING DIMENSIONS
Dimensions (WxHxD) (in.)
| 22.1 x 10.8 x 24.4 |
Dimensions (WxHxD) (mm.)
| 560 x 275 x 620 |
Weight (lbs.)
| 85.5 |
Weight (kg.)
| 38.8 |
ENVIRONMENTAL
Operating Temperature (?F)
| 32 ~ 104 |
Operating Temperature (?C)
| 0 ~ 40 |
Operating Relative Humidity (Non-condensing)?(%)
| 0 ~ 95 |
Operating Elevation?(feet/meters)
| 0-10,000 feet (0-3,000 meters) |
Storage Temperature (?F)
| 5 ~ 113 |
Storage Temperature (?C)
| -15 ~ 45 |
Storage Relative Humidity (Non-condensing)?(%)
| 0 ~ 95 |
Storage Elevation?(feet/meters)
| 0-50,000 feet (0-15,000 meters) |
Online Thermal Dissipation?(BTU/hr)
| 71.7 |
Audible Noise at 1.0M from Surface of Unit?(dBA)
| 55.5 |
CERTIFICATIONS
Certifications
| CE?,?FCC Class B?,?UL?,?RCM?,?VCCI |
RoHS
| Yes |
